Technical Data

GENERAL

• Input voltage: 100 - 240 VAC
• Input frequency: 50/60 Hz
• Input current: 1.5 A
• Input connector: EU (Type C)
• Output voltage: 48 VDC
• Output current: 1.3 A
• Output connector: 2-PIN, with cord end terminals
• Weight: 305 g

ADDITIONAL

• Input voltage absolute maximum: 90 - 264 VAC
• Input frequency absolute maximum: 47 - 63 Hz
• Maximum input inrush current: 50 A
• Output voltage absolute maximum: 45.6 - 50.4 VDC
• Short circuit protection: yes
• HIPOT (dielectric withstand test): Primary to Secondary: 4000 VDC
• MTBF: 50000 h
• Certification Safety: EN 61558-1:2005/A1:2009, EN 61558-2-16:2009/A1:2013 (CB Scheme)
• Certification EMC: EN 55032:2012+AC:2013, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015
