Model

 HDS3102M-N

 Bandwidth

 100MHz

 Sample Rate (real time )

 1GS/s

 Horizontal Scale (s/div)

5ns/div～100s/div, step by 1～2～5

 Display

 3.7” color TFT display (640 × 480 pixels)

 Channel

 dual

 Record Length

6K points

 Input Coupling

 DC, AC, and GND

 Vertical Sensitivity

 5mV/div～5V/div (at input)

 Vertical Resolution (A/D)

 8 bits

 Trigger Type

 Edge, Video, and Alternate

 Acquisition Mode

 Sample, Peak Detect, and Average

 Waveform Math

 ＋, －, ×, ÷, invert, FFT

 Communication Interface

 USB

 Power Supply

 100V-240V AC, 50/60Hz

 Li-ion Battery

 7.4V, 6 hours’ operation

 Dimensions (W × H × D)

 115 × 180 × 40 (mm)

 Weight (without package)

 645.00 g

Multimeter Specifications

Full Scale Reading

 3(3/4) digit (max 4000-count)

 diode

 0V-1V

Input Impedance

 10 MΩ

 On / Off Test

 < 50 (± 30) beeping

Voltage

VDC : 400mV, 4V, 40V, 400V, 1000V : ±(1% ± 1 digit); max input : DC 1000V
VAC : 4V, 40V, 400V : ±(1% ± 3 digits), 750V : ±(2% ± 3 digits); Frequency : 40Hz - 400Hz;
max input : AC 750V (virtual value)

Current

DC : 40mA, 400mA : ±(1.5% ± 1 digit), 10A : ±(3% ± 3 digits)
AC : 40mA : ±(1.5% ± 3 digits), 400mA : ±(2% ± 1 digit), 10A : ±(5% ± 3 digits)

Impedance

 400Ω : ±(1% ± 3 digits), 40ΚΩ - 4ΜΩ : ±(1% ± 1 digit), 40MΩ : ±(1.5% ± 3 digits)

Capacitance

 51.2nF - 100uF : ±(3% ± 3 digits)
