Ominaisuudet:

• Full Gigabit Ethernet ports
• IEEE 802.3af/at, PoE+ standards
• Up to 36 W output per PoE port
• Supports 9.6 KB jumbo frames
• Intelligent power consumption detection and classification
• Smart PoE overcurrent and short-circuit protection
• IP30-rated metal housing
• 0 to 60°C operating temperature range

Speksit:

• IEEE 802.3 for 10BaseT
• IEEE 802.3ab for 1000BaseT(X)
• IEEE 802.3af/at for PoE/PoE+ output
• IEEE 802.3u for 100BaseT(X)
• IEEE 802.3x for flow control
• IEEE 802.3z for 1000BaseX

Standardit ja sertifikaatit:

• Safety

   UL 508

• EMC

  EN 61000-6-2/-6-4

• EMI

  CISPR 32, FCC Part 15B Class A

• EMS

  IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
  IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
  IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
  IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
  IEC 61000-4-6 CS: 10 V
  IEC 61000-4-8 PFMF

• Shock

  IEC 60068-2-27

• Vibration

  IEC 60068-2-6

• Freefall

  IEC 60068-2-32

• Railway

           EN 50121-4

Tulojännite:

• 12/24/48 VDC, Redundant dual inputs
