Serial to Ethernet Module ESP32

SEEED 102991455

2 kappaletta

Varastossa

Huom: Viimeinen tuote varastossa!

Valmistajan kotisivu

30,76 €

Seeed Studio 102991455 - Serial to Ethernet Module based on ESP32 series - WT32-ETH01 - WT32-ETH01 is an embedded serial to Ethernet module based on the ESP32 series WT32-S1 MCU.

WT32-ETH01 is an embedded serial to Ethernet module based on the ESP32 series WT32-S1 MCU. The module integrates an optimized TCP/IP protocol stack, which is convenient for users to easily complete the networking functions of embedded devices while reducing development time cost. In addition, the module is compatible with half-pad and through-hole connectors. The board width is a universal width and therefore, it can be directly soldered to boards, connectors, or even breadboards, which is convenient for users to use in different scenarios.

The ESP32 series of ICs are SOCs that integrate 2.4GHz Wi-Fi and Bluetooth dual-mode, with ultra-high radio frequency performance, stability, versatility, reliability, and ultra-low power consumption.

Features

  • Support complete TCP/IP protocol stack
  • Rich wireless communication interface
  • Multiple working modes using through holes and half-pads

Specifications

SpecificationItemsDetails
Wi-FiRF CertificationsFCC/CE/RoHS
Protocols802.11 b/g/n/e/i（802.11n，Up to 150 Mbps）
A-MPDU and A-MSDU aggregation, 0.4_ s guard interval support
Frequency range2.4~2.5 GHz
BluetoothProtocolsBluetooth v4.2 BR/EDR and BLE standards
RadioNZIF receiver with -97 dBm sensitivity
HardwareNetwork port specificationsRJ45, 10/100Mbps, Cross-direct connection adaptive
Serial baud rate80~5000000
On-board flash32Mbit
Operating voltage5V or 3.3V
Operating currentAverage: 80mA
Supply currentMinimum: 500 mA
Operating temperature-40°C~+85°C
Ambient temperatureNormal temperature
PackagingHalf pad/ Through-hole connector( Optional）
SoftwareWi-Fi modeStation/softAP/SoftAP+station/P2P
Wi-Fi security mechanismsWPA/WPA2/WPA2-Enterprise/WPS
Encryption typesAES/RSA/ECC/SHA
Firmware updateRemote OTA upgrade via network
Software developmentSDK used for further development
Networking protocolIPv4、TCP/UDP
IP access methodsStatic IP、DHCP（Default）
Transparent transmission modesTCP Server/TCP Client/UDP Server/UDP Client
User configurationsAT+ commands set

Part List

  • 1 x Serial to Ethernet Module based on ESP32 series - WT32-ETH01

Links

Klikkaa tarkemmat tiedot
ValmistajaSeeed Studio
Valmistajan malli102991455
Käyttölämpötila-40...+85°C
