Joy-IT RASPBERRY PI400 GPIO LLC

This logic level converter board allows the operation of devices with a logic level of 5 V at the 40-pin GPIO header of the Raspberry Pi. The logic level of the GPIOS can be switched between 3.3 V and 5 V with a jumper. Additionally, this board facilitates access to the GPIO header when used with the Raspberry Pi 400.

Specifications

• SPECIAL FEATURES: LLC channels (3 V / 5 V) for all GPIOs of the Raspberry Pi, optional pullup resistors for the I2C lines
• SUPPLY VOLTAGE VCCA: 3,3 V
• SUPPLY VOLTAGE VCCB: 3,3 V / 5 V
• COMPATIBLE WITH: Raspberry Pi 3 / 4 / 400
• DIMENSIONS: 44 x 55 x 12 mm
• WEIGHT: 15 g
• ITEMS SHIPPED: Logic level converter board

Links

• RB-LLC Datasheet English - 476,05 KB
• Manual English 22-11-2022 - 706,04 KB
