VIBRATION SWITCH 12VDC

Operation voltage

11 - 15 V direct current voltage

Own current consumption

in case of vibrations, motor runs (LED off): < approx. 0.000005A (< 5μA)

At rest, no vibrations (LED flashes)

< approx. 0.000008A (< 8μA)

Max. switching current (max. current consumption of the connected device)

1 A

At rest (no vibrations), the input voltage (11 - 15 V/DC) is switched through to the output and the connected device is in operation.

Switch-off delay during movement

approx. 3 seconds (depending on the intensity of the vibrations)

Switch-on delay at end of movement

approx. 22 seconds

Switching sensitivity

roughly adapted to the vibrations of an combustion engine in a motor vehicle

Operating temperature range

approx. -20°C to +70°C

Dimensions (without fixing straps)

approx. 60 x 45 x 20 mm
